Description
The MKGW2-LW gateway leverages the LoRaWAN protocol, integrating Semtech’s high-perfor-mance multi-channel transceiver (SX130X/SX125X) with the MTK platform for robust connectivity. Its compact design ensures effortless installation on roofs, walls, and in other indoor environments, making it ideal for smart factories, buildings, offices, and other IoT applications.
Specification
| LoRa Chipset | Semtech SX130X/125X |
| WIFI Chipset | MTK MT7688 with 128M DDR and 32M flash |
| Wi-Fi Frequencies | 2.4GHz |
| LoRaWAN Regions | EU868/US915/AU915/AS923-1/AS923-2/AS923-3/AS923-4/RU864/IN865/KR920 |
| LoRa wireless coverage | LoRa 4km in city environment |
| Power Supply | DC/POE USB |
| Dimension (mm) | 166 x 105 x 28.4 |
| Net Weight | 215g |
| Shell Material | ABS |
| Operating Temperature | -20℃~55℃ |
| Wireless Coverage | 130m (WIFI), 4km (LoRa) |
| Certification | CE, FCC, RoHS |
